基业箱自动出产设备-基业箱出产设备是郑州Abpay新一代智能设备，可实现基业箱箱体自动出产！！

基业箱自动出产设备-基业箱出产设备重要参数：：

总电机功率：：29kw

电压参数：：380V/415V，50Hz, 3相

电气节制：：PLC

驱动电机：：变频电机驱动

钢带厚度：：0.5~1.5 mm （视型材而定）

钢带宽度：：≤1000mm,（视型材而定）

轧辊材质：：铬十二 淬火HRC58°-62°

液压油型号：：46#液压油

资料规格：： 1、、Q235   2、、不锈钢  3、、镀锌钢板

折弯方式：：在线自动折弯成型

出产速度：：0-12 m/min

堵截方式：：液压堵截

堵截尺寸公差：：≤ ±0.3mm（长≤3000mm）

堵截模具材质：：铬十二钼钒

气源：：0.5m3/Min；；
；压力为0.8MPa

   “Abpay冷弯”我公司出产的配电箱成型流水线
。。动力柜柜体出产设备，配电箱箱体自动折弯成型机、、消防箱出产线，光纤箱出产线等可凭据客户的分歧出产、、工艺需要，设备配置，集成出产所需的众多工艺—自动送料、、冲孔、、折弯、、成型
。。：笮裳∨浠凳趾附拥鹊龋；
；

配电箱成型流水线设备，——“Abpay冷弯”我们更专业！！

Main parameters of distribution box forming line: total motor power: 29kw voltage parameter: 380V < 415V, 50Hz, 3-phase electrical control: PLC drive motor: frequency conversion motor drive steel strip thickness: 0.51.5 mm (depending on profile) steel strip width: ≤ 1000mm, (depending on profile) Roller material: chromium 12 quenched HRC58 °- 62 °hydraulic oil model: 46 # hydraulic oil material specification: 1, Q2352, stainless steel 3, Galvanized steel sheet bending mode: on-line automatic bending forming production speed: 0 to 12 m/min cutting mode: hydraulic cutting dimensional tolerance: ≤ ±0.3mm (length ≤ 3000mm) cutting die material: chromium 12 molybdate vanadium Gas source: 0.5m3 Minmin; The pressure is 0.8MPa "Wei Hua cold bending" our company produces the distribution box forming assembly line. Power cabinet production equipment, distribution box automatic bending molding machine, fire box production line, optical fiber box production line, etc., according to the customer's different production, process requirements, equipment configuration, Integrate many processes needed for production-automatic feeding, punching, bending, forming. Follow-up optional manipulator welding and so on; distribution box forming assembly line equipment,-"Wei Hua cold bending" we are more professional!
